• Your Pathfinder needs to be have Rock Creek roofrack from Nissan, or aftermarket roof rack -- the original Pathfinder roof rack (except Rock Creek) does not have good mounting spots for Sherpa
• Aftermarket roof racks with metal round bars would work, as would aftermarket roof racks with metal constructions
• Water container is ready to serve with turn of a lever with GoWesty spout (see Links page)
Pathfinder22 Sherpa
$
0
Expires 2024-12-31
1 15:03:57
Rear View
• Multiple locations for mounting Rotopax containers (square holes)
• Wider Rotopax container sepraation allows for installing fire extinguisher between them
Powder coated Sherpa
• Passenger side main panel has extra holes for better driver visibility
Front View
• Mounted on driver side
• Can be on eitehr or both side with a separate wing panel on top
Main panel layout
• 2 positions for left Rotopax container
• 3 positions for right Rotopax container
• Fire extinguisher mount holes in between
Side view
• Showing maximum container separation to fit fire extinguisher in between
• Containers can be 2 inches closer by using other mounting locations
Rock Creek roof rack
• Sherpa on Pathfinder needs Rock Creek roof rack (it might be possible to install it on other Pathfinders), or aftermarket roof racks
Rotopax and fire extinguisher
Maxtrax on Maxtrax panel
• Maxtrax panel is as long as needed for Maxtrax mounting holes
• Maxtrax pins allow easy on/off (sold where Maxtrax are sold; hold 2 or 4 Maxtrax)
L panel on top
• 3/16 inch thick aluminum
• holds main panel (same thickness)
• powder coat is textured
• can be used without main panel, to hold treadboards/Maxtrax
Suction cups used
• 2 used per side, with 2 different risers
• center mounted studs, mount through aluminum panels with 1/4 inch nuts
Construction
• separate product for driver's side, another for passenger side
• Aluminum panels won't rust and weigh around 10lb, angled brackets + large panel
• Stainless steel hardware, nylon insert self locking nuts; 3/16 hex head front and 5/16 back nuts
• Rubber pads separate panel from glass
• mounts in 2 parts for easier installation, angled top bracket first
• powder coated black, or raw aluminum for your own custom painting
Usage
• 1 or 2 RotoPax containers sit side by side, 2 gallons each, 1, 1.5...
• tread boards can also be mounted, but will stick out from the back if youurs are 45+ inches long
• all holes (slits and X shapes) are 1/4 inch wide, allow for attaching your own bolts for future accessories
• wide hole strips, vertical and horizontal, allow for strap attachments
• 4 hole square pattern on main panel is for Rotopax mounts (2 1/8 inch square holes fit the square Rotopax bolt mounts)
• customizing: drill your own holes if needed in the future (measure twice)
Gear to get
• Compare prices from Rotopax.com to GoWesty.com and Amazon.com
